1.1.2 · D5Measurement, Vectors & Kinematics

Question bank — SI units — seven base units and all derived units

1,926 words9 min readBack to topic

For the parent overview, return to SI units — seven base units and all derived units. Several traps here are really about dimensions, so keep Dimensional Analysis in mind, and a couple touch Vectors and Scalars and Kinematics — velocity and acceleration.


A picture of what a "trap" really is

Figure — SI units — seven base units and all derived units

The left panel is the tree: notice how newton, joule and pascal all trace back only to , , — no new root is ever added. The right panel shows the cancellation: when you divide metre by metre (a strain, a radian), every unit crosses out and you land on the amber "1" — a dimensionless result.


True or false — justify

Recall

The kilogram is the only SI base unit whose name carries a prefix. ::: True — "kilo" is baked into the base unit of mass, unlike metre or second which are prefix-free; this is a historical accident, not a logical rule. A quantity can have units yet be dimensionless. ::: True — an angle in radians is metre/metre, a pure ratio; it is dimensionless yet we still write "rad" to signal it is an angle. Two quantities with the same base-unit form must be the same physical quantity. ::: False — torque and energy are both yet one is a rotational effect and the other is work; identical dimensions do not force identical meaning. Frequency (Hz) and radioactivity (Bq) and angular frequency all reduce to . ::: True in base units — but note angular frequency is conventionally written (radian being a dimensionless name), and , so a spin is even though both strip down to . Angular frequency in rad/s equals frequency in Hz. ::: False — they differ by the factor : , because one full cycle (1 Hz) sweeps radians; the radian "unit" is dimensionless so it hides this factor in the base-unit form. The mole is a base unit even though it is "just a number" (). ::: True — amount of substance is declared an independent base quantity by convention; the mole counts entities and cannot be built from the other six. Celsius degrees and kelvin degrees are the same size. ::: True — only the zero point differs (); a rise of 1 °C equals a rise of 1 K, so temperature differences are numerically identical. Since (the speed of light) is now a fixed exact number, measuring it more carefully could change its value. ::: False — after the 2019 redefinition is defined exact; better experiments now refine the metre, not . The litre is an SI unit. ::: False — the litre is an accepted non-SI unit; the coherent SI volume unit is the cubic metre (), and the litre is merely tolerated for convenience.


Spot the error

Recall

"Force is so fundamental in mechanics that the newton must be a base unit." ::: Error — force is derived from (mass times acceleration), so its unit is built from mass, length and time; the base set of mechanics is only those three. "Weight and mass are both measured in kilograms." ::: Error — mass is in kilograms, but weight is a force measured in newtons; confusing them mixes a base quantity with a derived one. "°C is an SI base unit because temperature is a base quantity." ::: Error — the base unit of temperature is the kelvin; Celsius is a shifted convenience scale derived from it, not a base unit. "The gram is the SI base unit; the kilogram is just 1000 grams." ::: Error — officially the kilogram (prefix included) is the base unit; the gram is defined from it, not the other way round. "Pressure is force, so its unit is the newton." ::: Error — pressure is force per area, so the pascal is ; dividing by area changes the dimensions. "A mole of electrons and a kilogram of electrons describe the same amount of stuff." ::: Error — the mole counts particles while the kilogram measures inertia/mass; they are different base quantities answering different questions. " can't be right dimensionally because energy shouldn't equal mass." ::: Error — with energy, mass, speed of light, the check works: , exactly energy; the constant carries the missing dimensions. "The prefix on a kilometre and a kilogram means both are 1000 base units." ::: Error — a kilometre is metres (base unit metre), but a kilogram is itself the base unit; you cannot stack another prefix on it, so a "kilo-kilogram" is a tonne (Mg), not a base unit. "You may write (microkilo) instead of milli." ::: Error — SI forbids compound prefixes; only one prefix at a time attaches to a unit, so it must be milli (m), never micro-kilo.


Why questions

Recall

Why were the base units redefined in 2019 using constants of nature instead of physical objects? ::: Objects drift, scratch, and can be lost (the old kilogram cylinder actually changed mass); fixing a constant of nature gives a standard that never varies and is reproducible in any lab. Why is luminous intensity (candela) a base quantity when it seems like a form of power? ::: The candela is weighted by the human eye's response to different wavelengths, so it cannot be reduced to raw watts; that human-centred weighting makes it independent enough to be declared base. Why can't temperature be built out of energy, even though heat and energy feel linked? ::: The link needs the Boltzmann constant to convert energy to temperature; declaring temperature independent lets do the translating rather than forcing kelvin to be a derived energy unit. Why do we bother naming derived units (newton, joule) instead of always writing base units? ::: The named units compress long strings like into one word, making equations readable — but you can always unfold them back to base units to check dimensions. Why is a pure number like ignored in a unit check? ::: Dimensionless constants carry no units, so they cannot change the base-unit form; only the quantities with dimensions determine the unit. Why must the seven base quantities be dimensionally independent? ::: If one could be written from the others it would be redundant — you'd have more standards than necessary; independence guarantees a minimal, non-overlapping "basis" for all measurements. Why is the electronvolt (eV) allowed in physics if it is not an SI unit? ::: It is a tolerated non-SI unit sized to atomic energies (); it is convenient but must be converted to joules before it fits coherently into SI equations.


Edge cases

Recall

What is the base-unit form of a quantity that is truly dimensionless, like refractive index or strain? ::: It has no base units at all — refractive index is a ratio of speeds and strain is length/length, so every base unit cancels and the answer is (pure number); see the amber "1" in the figure. Does adding two quantities with the same units but different meanings (e.g. torque + energy) make physical sense? ::: No — even though both are , physics forbids adding a rotational torque to an energy; matching units is necessary but not sufficient for a valid sum. If a formula gives a dimensionless argument to a function like or , what does that tell you? ::: Such functions demand dimensionless inputs, so the argument's units must cancel; if they don't, the formula is wrong — a powerful consistency check. At absolute zero (0 K), what happens to the Celsius reading, and is 0 K reachable? ::: ; it is the theoretical floor of temperature but the third law of thermodynamics says it can be approached, never exactly reached. Can a derived unit ever "become" a base unit? ::: In principle the choice of which quantities are base is a convention — SI could have chosen force as base and mass as derived; the current seven are picked for practicality, not because they are uniquely fundamental. Is angular measure (radian) a base unit, a derived unit, or neither? ::: Neither in the usual sense — the radian is a dimensionless derived unit, defined as arc length over radius (metre/metre), so it has a name but no dimensions. Where does the steradian fit — and how is it different from the radian? ::: Same category as the radian: a dimensionless named derived unit, but for solid angle, defined as area on a sphere over radius-squared (); both carry names yet vanish in base units. What is the unit of a quantity raised to the zeroth power, e.g. ? ::: It is dimensionless (); any unit to the power zero cancels itself, leaving a pure number with no base units. Are the minute, hour, tonne and bar part of SI? ::: No — they are accepted for use with SI but are non-coherent: minute/hour (, ), tonne (), bar (); a "coherent" unit needs no such conversion factor, which is why the second, kilogram and pascal are preferred. What does "coherent" mean for a derived unit? ::: A coherent unit comes out of its defining equation with a conversion factor of exactly (e.g. ); units like the litre or bar are non-coherent because a power-of-ten factor sneaks in.
