Adiabatic flame temperature — calculation with enthalpies of formation: Question bank

Before the traps, three tiny "so we speak the same language" panels. Skip them only if the notation is already second nature.

Definition The First-Law symbols, in plain words

$Q$ = heat: energy that crosses the system boundary because of a temperature difference (flows in as $+$ , out as $-$ ). For an adiabatic flame, $Q = 0$ by definition (perfectly insulated — nothing leaks out).
$W_{shaft}$ = shaft work: useful work delivered through a spinning shaft, piston rod, etc. A free-burning flame has none, so $W_{shaft} = 0$ .
$p d V$ work = expansion work: the push the gas exerts on its surroundings as its volume $V$ swells against pressure $p$ . At constant pressure this is exactly what the enthalpy bookkeeping already absorbs.
$H$ = enthalpy $= U + p V$ (internal energy plus the $p V$ term). Its change is written $Δ H = H_{final} - H_{initial}$ .
The First Law of Thermodynamics for a constant-pressure process with no shaft work collapses to $Q = Δ H$ . Set $Q = 0$ and you get $Δ H = 0$ . See First Law of Thermodynamics.

Figure — Adiabatic flame temperature — calculation with enthalpies of formation

True or false — justify

Each line: the claim, then :::, then the honest verdict with the reason.

True or false: "Adiabatic means the reaction releases no energy."

False. Adiabatic means no heat crosses the boundary (

Q = 0

); the reaction still releases exactly as much chemical energy as always — that energy is trapped inside and shows up as the products' sensible heat instead of leaking out.

True or false: "For a constant-pressure adiabatic flame,

Δ H = 0

for the whole process."

True. With

Q = 0

and no shaft work at constant

p

, the First Law

Q = Δ H

gives

Δ H = 0

, so

H_{prod} (T_{ad}) = H_{react} (T_{in})

. Enthalpy is merely redistributed from chemical to thermal form.

True or false: "Because

Δ H = 0

, the reaction enthalpy

Δ H_{rxn}^{\circ}

must also be zero."

False.

Δ H_{rxn}^{\circ}

(measured at a fixed 298 K) is very negative; it is the products' sensible heat that grows to exactly cancel it, keeping the total

Δ H

of the actual (temperature-changing) process at zero.

True or false: "The adiabatic flame temperature is a property of the fuel alone."

False. It depends on fuel and oxidizer and mixture ratio and any inert diluent — the same methane gives ~2340 K in air but ~5800 K in pure O₂ because N₂ acts as a thermal sponge.

True or false: "Nitrogen does not appear in the energy balance because it is inert."

False. N₂ is chemically inert (no formation-enthalpy change) but it is heated from 298 K to

T_{ad}

, so its sensible-heat term

n_{N_{2}} \overset{ˉ}{C}_{p, N_{2}} (T_{ad} - 298)

sits squarely on the left side and is usually the largest single term.

True or false: "Using liquid-water

Δ H_{f}^{\circ} = - 285.8

kJ/mol gives a more accurate AFT than the vapor value."

False. At flame temperatures water is vapor, so the correct basis is

- 241.8

kJ/mol. The liquid value bundles in condensation (latent) heat that is never actually released in the flame, overstating the energy available.

True or false: "The constant-

C_{p}

, no-dissociation estimate always overshoots the real AFT."

True. Real

C_{p}

rises 30–50 % from 300→2500 K (soaks more heat per kelvin) and high-

T

dissociation absorbs energy; ignoring both under-counts heat sinks, so the estimate lands above reality.

True or false: "Constant-volume and constant-pressure adiabatic flame temperatures are identical."

False. At constant volume no expansion (

p d V

) work is done, so more energy stays as internal energy and

T_{ad}

is higher; the constant-pressure case does expansion work against the surroundings and runs cooler.

True or false: "If you preheat the reactants above 298 K,

T_{ad}

rises."

True. Preheating adds a positive reactant sensible-heat term, so the products must carry even more thermal energy to keep total enthalpy equal — pushing

T_{ad}

up. (This is why regenerative preheating is used in furnaces.)

Why questions

"Why do we split each species' enthalpy into a formation part plus a sensible-heat part?"

Because tables only give us

Δ H_{f}^{\circ}

at one reference (298 K); the sensible integral

\int_{298}^{T} C_{p} d T

is the bookkeeping device that carries a molecule from that reference up to any flame temperature.

"Why can we treat reactants' sensible heat as zero in the standard derivation?"

We assume reactants enter at the reference temperature 298 K, so

\int_{298}^{298} C_{p} d T = 0

and only the products' thermal term survives — this is a convenience, not a law, and fails if reactants are preheated.

"Why does pure-oxygen combustion burn so much hotter than air combustion?"

Air drags ~3.76 mol inert N₂ per mol O₂; that N₂ soaks energy without contributing any, so the released heat spreads over far more moles. Remove it and the same energy concentrates in fewer product moles → much higher

T_{ad}

"Why does dissociation lower the achievable flame temperature?"

Splitting stable products like

H_{2} O

into

OH

H

O

is endothermic; above ~2500 K it consumes a chunk of the released energy, so less remains as sensible heat and

T_{ad}

is capped near ~3000 K instead of the naive ~5000+ K. See Chemical equilibrium and dissociation at high temperature.

"Why is enthalpy (not internal energy) the conserved quantity for the standard AFT?"

Because the standard problem is at constant pressure with no shaft work; the First Law then reduces to

Q = Δ H

, and

Q = 0

makes enthalpy the invariant. (For a rigid sealed bomb, internal energy

U

is conserved instead.)

"Why does adding a cold inert diluent (like extra N₂ or steam) cool the flame even though it takes part in no reaction?"

It contributes zero to the numerator (no chemical energy) but adds moles to the denominator

\sum n_{j} \overset{ˉ}{C}_{p, j}

, so the same released heat divides across more thermal mass — directly analogous to adding cold water to hot soup.

Edge cases

"What happens to

T_{ad}

as the mixture becomes extremely lean (huge excess air)?"

The denominator grows without bound while the numerator stays fixed, so

T_{ad} \to 298

K (the inlet temperature) in the limit — infinite dilution simply refuses to ignite meaningfully and the mixture stays near room temperature. See Stoichiometric vs lean vs rich mixtures.

"What is the AFT of a mixture with no fuel at all?"

With

Δ H_{rxn}^{\circ} = 0

, the sensible term must be zero, forcing

T_{ad} = 298

K. No chemistry, no heating — a useful sanity check that the formula behaves at the degenerate boundary.

"For a fuel-rich mixture (excess fuel, too little O₂), why can't we simply plug into the same formula?"

Oxygen runs out, so combustion is incomplete and products shift toward

CO

H_{2}

, soot; the balanced equation and

Δ H_{rxn}^{\circ}

change entirely. You must re-balance for the actual product set before any energy balance is valid.

"Where does the maximum AFT sit — exactly at stoichiometric, lean, or slightly rich?"

Slightly on the fuel-rich side of stoichiometric in real flames: dissociation and specific-heat effects shift the peak, but as a first approximation stoichiometric mixtures give near-maximum AFT because there is neither excess cold air nor unburned fuel to dilute the heat.

"If a product could condense at

T_{ad}

(say water in a very cool flame), what breaks in the analysis?"

The sensible-heat integral assumes a single gaseous phase; a phase change would inject latent heat and a discontinuity in

C_{p}

, so you'd need to add the condensation enthalpy explicitly — which is exactly why using liquid-water

Δ H_{f}^{\circ}

for a hot vapor flame is wrong.

Recall One-line trap summary

Almost every AFT trap is one of three sins: (1) forgetting that inert species still heat up, (2) mixing up liquid vs vapor water enthalpy, or (3) trusting constant $C_{p}$ with no dissociation at temperatures where both assumptions fail. The three sins ::: Ignoring inert sensible heat; wrong water phase enthalpy; constant- $C_{p}$ /no-dissociation overshoot.
