4.3.5Halides and Oxygenated Derivatives

Phenols — acidity (resonance stabilization), Kolbe-Schmidt, Reimer-Tiemann, Fries rearrangement

2,022 words9 min readdifficulty · medium

1. Acidity of Phenols

WHY is phenol more acidic than alcohols? An acid is strong when its conjugate base is stable (it doesn't want the H⁺ back).

  • In ethoxide (CH3CH2O\text{CH}_3\text{CH}_2\text{O}^-), the negative charge is stuck on one oxygen. Nothing spreads it out.
  • In phenoxide (C6H5O\text{C}_6\text{H}_5\text{O}^-), the charge is delocalized into the ring by resonance. Spread-out charge = lower energy = more stable = phenol gives up H⁺ more readily.

Substituent effects (this is the 80/20 exam content)

Phenol pKapK_a Why
Phenol 10.0 baseline
p-cresol (pp-CH₃) 10.3 CH₃ donates → less acidic
p-nitrophenol 7.1 -NO₂ withdraws (resonance + inductive) → more acidic
2,4-dinitrophenol 4.0 two EWG
2,4,6-trinitrophenol (picric acid) 0.4 three EWG → as strong as a mineral acid!
Figure — Phenols — acidity (resonance stabilization), Kolbe-Schmidt, Reimer-Tiemann, Fries rearrangement

2. Kolbe–Schmidt Reaction (→ salicylic acid → aspirin)

HOW (mechanism, from scratch):

  1. Make the nucleophile: Phenol + NaOH → sodium phenoxide. Phenoxide ring is very electron-rich (extra negative charge).
  2. CO₂ is the electrophile: the carbon of O=C=O\text{O=C=O} is electrophilic.
  3. Electrophilic substitution at ortho: the ortho carbon attacks the CO₂ carbon (this is an EAS-like / nucleophilic-aromatic-on-electrophile step). Ortho is favoured because the phenoxide O can chelate the Na⁺ to the incoming carboxylate, holding it nearby.
  4. Rearomatise + tautomerise → sodium salicylate. Acidify → salicylic acid.

3. Reimer–Tiemann Reaction (→ salicylaldehyde)

HOW (mechanism — the key is dichlorocarbene):

  1. NaOH deprotonates CHCl₃: CHCl3+OH:CCl3+H2O\text{CHCl}_3 + \text{OH}^- \to \text{:CCl}_3^- + \text{H}_2\text{O}.
  2. :CCl3\text{:CCl}_3^- loses Cl\text{Cl}^-dichlorocarbene :CCl2\text{:CCl}_2 — a neutral, electron-deficient electrophile.
  3. Phenoxide's electron-rich ortho carbon attacks :CCl2\text{:CCl}_2 → gives an Ar–CHCl₂ (benzal chloride) intermediate at the ortho position.
  4. Hydrolysis of –CHCl₂ by NaOH → –CHO. Acidify → salicylaldehyde.

4. Fries Rearrangement (→ acyl phenols)

HOW (mechanism):

  1. AlCl3\text{AlCl}_3 coordinates to the ester carbonyl O, weakening the O–acyl bond.
  2. An acylium ion R–CO+\text{R–C}\equiv\text{O}^+ (or AlCl₃–acyl complex) breaks off — this is the electrophile.
  3. Friedel–Crafts acylation of the now-free phenol ring (electron-rich, –OH is an o/p director) at ortho or para.
  4. Work-up → hydroxy aryl ketone.

5. Quick comparison table

Reaction Reagent / electrophile Product group introduced Position
Kolbe–Schmidt CO₂ + pressure (on Na phenoxide) –COOH ortho (Na)
Reimer–Tiemann CHCl₃/NaOH (:CCl₂) –CHO ortho (mainly)
Fries aryl ester + AlCl₃ –COR (ketone) o (hot) / p (cold)

Recall Feynman: explain to a 12-year-old

Imagine phenol is a ball (H⁺) lightly stuck to a glove (oxygen) attached to a big trampoline (the ring). When the ball pops off, the leftover "stickiness" (negative charge) doesn't stay in one spot — it bounces all over the trampoline. Because the stickiness is spread out, the ball comes off easily — that's why phenol is sour-ish (acidic). The same electron-rich trampoline lets phenol grab passing molecules (CO₂, a carbene, an acyl piece) and stick them onto its edges (ortho/para) — that's Kolbe, Reimer–Tiemann, and Fries.


Active-Recall Flashcards

#flashcards/chemistry

Why is phenol more acidic than ethanol?
Its conjugate base (phenoxide) delocalizes the negative charge into the ring by resonance; ethoxide cannot, so its charge stays localized on O.
Approximate pKa of phenol vs ethanol vs acetic acid?
Phenol ~10, ethanol ~16, acetic acid ~4.76.
Why is acetic acid more acidic than phenol?
Carboxylate spreads charge over two electronegative oxygens; phenoxide spreads it onto carbon atoms (worse at holding negative charge).
Effect of a p-NO₂ group on phenol acidity and why?
Increases acidity (pKa ~7.1); EWG at o/p stabilizes phenoxide's negative charge by resonance.
Why must the EWG be ortho/para (not meta) for strong acidification?
Resonance delocalization reaches only o/p carbons; meta can only act by weak inductive effect.
What is picric acid and its pKa?
2,4,6-trinitrophenol, pKa ~0.4 — three EWGs make it as strong as a mineral acid.
Kolbe–Schmidt: reagents, conditions, product?
Sodium phenoxide + CO₂, ~125 °C and pressure, then H⁺ → salicylic acid (2-hydroxybenzoic acid).
Why does Kolbe–Schmidt give ortho with sodium phenoxide?
Na⁺ chelates the phenoxide O and incoming carboxylate, directing substitution to ortho.
Reimer–Tiemann: reagents and the actual electrophile?
Phenol + CHCl₃ + NaOH; the electrophile is dichlorocarbene :CCl₂ generated in situ.
Reimer–Tiemann product and where?
Salicylaldehyde (2-hydroxybenzaldehyde), –CHO introduced ortho to –OH.
Fries rearrangement: starting material, catalyst, product?
Aryl ester (ArO–COR) + anhydrous AlCl₃, heat → ortho/para hydroxy aryl ketone.
Fries: how does temperature control regiochemistry?
High temperature → ortho (intramolecular H-bonding); low temperature → para.
Mechanistic electrophile in Fries?
Acylium ion R–C≡O⁺ (AlCl₃–acyl complex) that does Friedel–Crafts acylation on the freed phenol.
Which reaction gives –COOH, which –CHO, which –COR?
Kolbe–Schmidt → –COOH; Reimer–Tiemann → –CHO; Fries → –COR (ketone).

Connections

  • Resonance and Mesomeric Effect
  • Acid Strength and Conjugate Base Stability (pKa)
  • Electrophilic Aromatic Substitution
  • Friedel-Crafts Acylation
  • Carbenes and Dichlorocarbene
  • Aspirin and Salicylic Acid (applications)
  • Inductive vs Mesomeric Effects of Substituents

Concept Map

makes

makes

explains

more acidic than

less acidic than

charge on two O

charge on carbons

stabilizes phenoxide

destabilizes charge

enables

includes

O lone pair conjugates with ring

Phenoxide resonance stabilized

Ring electron-rich at o/p

Phenol is weak acid pKa 10

Ethanol pKa 16

Carboxylic acid pKa 5

Better charge holding

EWG at o/p e.g. NO2

More acidic lower pKa

EDG e.g. CH3

Less acidic

Electrophilic substitution

Kolbe-Schmidt Reimer-Tiemann Fries

Hinglish (regional understanding)

Intuition Hinglish mein samjho

Dekho, phenol ka pura khel ek baat pe tika hai: oxygen ka lone pair benzene ring ke andar "ghus" jaata hai (resonance). Jab phenol apna H⁺ chhodta hai, toh jo phenoxide banta hai uska negative charge sirf oxygen pe nahi rehta — wo ring ke ortho aur para carbons pe spread ho jaata hai. Charge jab phaila hua ho, toh anion zyada stable hota hai, aur stable anion matlab acid strong. Isiliye phenol (pKa ~10) alcohol (pKa ~16) se zyada acidic hai. Lekin carboxylic acid (pKa ~5) phenol se bhi strong hai, kyunki uska charge do oxygens pe baithta hai — oxygen carbon se behtar negative charge sambhalta hai.

Substituent effect simple hai: agar ortho/para pe electron-withdrawing group (jaise –NO₂) ho, to wo negative charge ko aur sambhal leta hai → acidity badhti hai (picric acid pKa 0.4, almost mineral acid jaisa!). Electron-donating group (–CH₃, –OCH₃) ulta charge ko dhakka deta hai → acidity kam. Meta position se sirf inductive thoda help karta hai, resonance nahi — isiliye o/p strong matter karte hain.

Ab reactions: phenol ki ring electron-rich hai, toh wo electrophiles ko pakad ke ortho/para pe chipka leti hai. Kolbe–Schmidt: sodium phenoxide + CO₂ (pressure, ~125°C) → salicylic acid (–COOH ortho). Yahi aage aspirin banta hai. Reimer–Tiemann: CHCl₃ + NaOH se banta hai dichlorocarbene (:CCl₂) — yahi asli electrophile hai, CHCl₃ khud kuch nahi karta — aur milta hai salicylaldehyde (–CHO ortho). Fries: phenol ka ester + AlCl₃ heat karo, acyl group O se ring pe shift ho jaata hai → hydroxy aryl ketone (–COR). Yaad rakho: Hot = Ortho, Cold = Para.

Trick yaad rakhne ka: K-CO₂-acid, R-Carbene-aldehyde, F-ester-ketone. Bas itna pakka kar lo, exam me yeh chapter point dilwa dega.
