Convolutional neural networks — convolution operation, pooling: Worked examples

This is the worked-examples deep dive for Convolutional neural networks — convolution & pooling. The parent gave you the formulas; here we stress-test them against every case class — every sign of the output, every degenerate input, the limiting behaviour of stride and padding, a real aerospace word problem, and an exam twist.

Before we start, one reminder of the two formulas everything below leans on. If either symbol is unfamiliar, re-read the parent — but we re-explain each as it appears.

Recall Three parent-page facts we lean on (so you don't need the parent open)

The parent listed common mistakes; we cite three by name. Restated plainly:

Pooling has zero learnable parameters — max/average is a fixed function, not trained.
Stride is not just a speed knob — a larger $s$ directly shrinks the output via the size formula.
Conv parameters are independent of image size — they depend only on $F (k^{2} C + 1)$ , never on $W_{in}$ .

The scenario matrix

Every problem this topic can hand you falls into one of these cells. The examples below are chosen so that together they touch every row.

#	Case class	What makes it tricky	Covered by
A	Padding preserves size (`p` chosen so $W_{o u t} = W_{in}$ )	the "same" convolution — is the arithmetic exact?	Ex 1
B	Non-divisible / floor kicks in	$(W_{in} - k + 2 p)$ not a multiple of $s$ → rounding down loses a position	Ex 2
C	Negative output value	a kernel producing $S < 0$ — signs matter, no clipping	Ex 3
D	Degenerate: $1 \times 1$ kernel, stride 1	is convolution still "doing" anything?	Ex 4
E	Limiting stride: $s = k$ (no overlap) & $s > 1$ shrink	how far can stride push before output hits 1?	Ex 5
F	Multi-channel filter (sum over depth)	parameter count and the extra sum	Ex 6
G	Pooling: max vs average, with a shift to prove invariance	does the max really not move?	Ex 7
H	Real aerospace word problem (crack-detector sizing)	translate words → numbers → layer stack	Ex 8
I	Exam twist: solve for an unknown ( $p$ or $s$ ) from a target size	invert the formula	Ex 9
J	Zero/empty degenerate: kernel bigger than input	when is $W_{o u t} \leq 0$ (invalid)?	Ex 10

The worked examples

Example 1 — Cell A: padding that preserves size

Example 2 — Cell B: the floor bites

Worked example Stride that does not divide evenly

Input $W_{in} = 7$ , kernel $k = 3$ , padding $p = 0$ , stride $s = 2$ . Find $W_{o u t}$ and list the exact kernel start positions.

Forecast: $(7 - 3) /2 = 2$ … is the answer 2, or 3? Guess.

Compute the numerator. $W_{in} - k + 2 p = 7 - 3 + 0 = 4$ . Why this step? This is the last valid start index — the furthest left the kernel's left edge can go and still fit. Positions run $0, 1, \dots, 4$ .
Divide by stride and floor. $⌊ 4/2 ⌋ = 2$ , then $+ 1 = 3$ . Why this step? With $s = 2$ the kernel only lands on start indices $0, 2, 4$ — every second position. That's 3 landings. The $+ 1$ counts position $0$ .
List the starts to check the floor. Starts $= {0, 2, 4}$ . A start at $6$ would need the window to occupy columns $6, 7, 8$ — but the last column is index $6$ , so $6$ overflows. Confirmed: 3 positions. Why this step? When the numerator is not a multiple of $s$ (e.g. change $W_{in}$ to 8: numerator 5, $⌊ 5/2 ⌋ = 2$ , still 3), the floor silently drops the leftover — this is exactly cell B's trap.
Verify: $⌊(7 - 3 + 0) /2 ⌋ + 1 = 2 + 1 = 3.$ ✓

Example 3 — Cell C: a genuinely negative output

Worked example Negative activation (no clipping yet)

Take the diagonal-edge kernel from the parent and a fresh patch: $I = [0950], K = [10 0 - 1], b = 0.$ Kernel $2 \times 2$ , so a single output value $S (0, 0)$ . Compute it.

Forecast: will the answer be positive, zero, or negative?

Overlay and multiply. $S (0, 0) = I (0, 0) \cdot 1 + I (0, 1) \cdot 0 + I (1, 0) \cdot 0 + I (1, 1) \cdot (- 1)$ . With $I (0, 0) = 0, I (1, 1) = 0$ , this gives $S = 0 \cdot 1 + 0 \cdot (- 1) = 0$ . Why this step? We follow the sum $\sum_{m} \sum_{n} I K$ ; only the $(0, 0)$ and $(1, 1)$ kernel entries are nonzero.
Now flip the patch's diagonal to $I^{'} = [9005]$ : $S^{'} = 9 \cdot 1 + 5 \cdot (- 1) = 9 - 5 = 4$ (positive). And $I^{''} = [2008]$ : $S^{''} = 2 - 8 = - 6$ (negative). Why this step? Convolution output is a signed number. A negative $S$ means "the top-left is dimmer than the bottom-right along the diagonal." Before any activation (e.g. ReLU), negatives are real and meaningful — do not clip prematurely.
Verify: $S^{''} = 1 \cdot 2 + (- 1) \cdot 8 = - 6.$ ✓ Sign correct: bottom-right ( $8$ ) larger than top-left ( $2$ ), and the kernel subtracts bottom-right, so output goes negative.

Example 4 — Cell D: the degenerate $1 \times 1$ kernel

Worked example Does a

$1 \times 1$ convolution do anything? Input $W_{in} = 6$ , kernel $k = 1$ , $p = 0$ , $s = 1$ , single channel, kernel value $K = [3]$ , bias $b = 1$ . What is $W_{o u t}$ and what does the layer compute per pixel?

Forecast: is a $1 \times 1$ conv just an identity, or something useful?

Output size. $W_{o u t} = ⌊(6 - 1 + 0) /1 ⌋ + 1 = 5 + 1 = 6$ . Size unchanged. Why this step? With $k = 1$ , the window is a single cell that fits everywhere; no shrinking.
What it computes. $S (i, j) = I (i, j) \cdot 3 + 1$ for every pixel. Why this step? The sum $\sum_{m, n}$ has only one term. So it's a per-pixel affine map — a scale ( $\times 3$ ) plus shift ( $+ 1$ ), applied identically everywhere.
The real point (multi-channel). A $1 \times 1$ kernel is not trivial when there are $C$ channels: it becomes a learned mix across channels at each pixel, $F (1 \cdot 1 \cdot C + 1)$ parameters (recall $F$ = number of filters) — used in aerospace pipelines to compress a stack of physics fields into fewer channels cheaply. Why this step? Shows the degenerate spatial case is still doing depthwise work.
Verify: for a pixel with $I = 4$ : $S = 4 \cdot 3 + 1 = 13.$ ✓ Size $6$ ✓.

Example 5 — Cell E: stride pushed to its limit

Example 6 — Cell F: a multi-channel filter

Worked example Summing over depth + parameter count

A single $2 \times 2$ filter over $C = 2$ channels, bias $b = 0$ . Input patch (channel 0 then channel 1) and kernel slices: $I_{0} = [1324], I_{1} = [0110], K_{0} = [1001], K_{1} = [2002] .$ Compute the single output value, then the parameter count for $F = 8$ such filters (recall $F$ = number of filters).

Forecast: one number comes out even though there are two channels — why one?

Convolve channel 0. $\sum I_{0} ⊙ K_{0} = 1 \cdot 1 + 2 \cdot 0 + 3 \cdot 0 + 4 \cdot 1 = 1 + 4 = 5$ . Why this step? Each channel is cross-correlated with its own kernel slice.
Convolve channel 1. $\sum I_{1} ⊙ K_{1} = 0 \cdot 2 + 1 \cdot 0 + 1 \cdot 0 + 0 \cdot 2 = 0$ .
Sum across channels + bias. $S = 5 + 0 + b = 5$ . Why this step? A filter outputs one feature per position; the channel results are added, collapsing depth $C$ into a single scalar. That is why RGB doesn't give 3 outputs per filter.
Parameter count. $F (k^{2} C + 1) = 8 (2^{2} \cdot 2 + 1) = 8 (8 + 1) = 72$ . Why this step? Each filter has $k^{2} C$ weights plus 1 bias; independent of image size (see the recall box).
Verify: output $= 5$ ✓; params $= 72$ ✓.

Example 7 — Cell G: pooling, and proving invariance under a shift

Figure — Convolutional neural networks — convolution operation, pooling

Worked example Max-pool vs average-pool, then shift the feature

$S = 1501362121934218, 2 \times 2, s = 2.$ Compute both pools. Then shift the "6" within its window and re-max-pool to test invariance.

Forecast: which pooling reacts to the shift, max or average?

Figure walkthrough (also readable without the image): the figure shows two copies of the top-left $2 \times 2$ window. On the left the value $6$ sits in the bottom-right cell of that window; on the right the $6$ has moved up one row (we swapped it with the $3$ ). In both copies the highlighted accent-red cell is the window's maximum, and in both it reads $6$ — the maximum's value is identical even though its position moved. That is the visual proof of invariance.

Max-pool the four windows. Top-left ${1, 3, 5, 6} \to 6$ ; top-right ${2, 4, 1, 2} \to 4$ ; bottom-left ${0, 2, 1, 1} \to 2$ ; bottom-right ${9, 1, 3, 8} \to 9$ . So $P_{ma x} = [6249]$ . Why this step? Non-overlapping windows because $s = k = 2$ ; max keeps the strongest "feature present?" signal.
Average-pool. Top-left $(1 + 3 + 5 + 6) /4 = 3.75$ ; top-right $(2 + 4 + 1 + 2) /4 = 2.25$ ; bottom-left $(0 + 2 + 1 + 1) /4 = 1$ ; bottom-right $(9 + 1 + 3 + 8) /4 = 5.25$ . $P_{a v g} = [3.75 1 2.25 5.25]$ .
Shift inside a window (invariance test). Move the top-left window's max from cell $(1, 1) = 6$ up to cell $(0, 1)$ (swap the $3$ and $6$ ). New window ${1, 6, 5, 3}$ → max still $6$ . This matches the accent-red cell in the figure: the maximum did not change value even though its position changed. Why this step? This is the whole point of pooling — local translation invariance. A wobble of one pixel leaves the max unchanged, so the network stops caring about exact position.
Contrast with average. The average of ${1, 6, 5, 3}$ is still $15/4 = 3.75$ — unchanged too, because we only permuted the same four numbers. But if the shift brings a new number into the window (e.g. from a neighbouring window), the max often survives while the average changes. That's why max is the standard invariance tool.
Verify: $P_{ma x} = [6249]$ , $P_{a v g} = [3.75 1 2.25 5.25]$ , shifted-window max $= 6$ . ✓

Example 8 — Cell H: aerospace word problem (crack detector)

Worked example Sizing a composite-panel crack detector

An inspection camera gives $256 \times 256$ single-channel panel images (Image classification for aerospace inspection). Your pipeline is: Conv ( $k = 5, p = 2, s = 1, F = 16$ ) → MaxPool ( $2 \times 2, s = 2$ ) → Conv ( $k = 3, p = 1, s = 1, F = 32$ ) → MaxPool ( $2 \times 2, s = 2$ ). Here $F$ is again the number of filters (output channels) of each conv. Find the spatial size after each stage and the parameters of each conv layer.

Forecast: guess the final spatial size — bigger or smaller than $64$ ?

Conv 1 size. $⌊(256 - 5 + 2 \cdot 2) /1 ⌋ + 1 = ⌊ 255 ⌋ + 1 = 256$ . Why? $p = (k - 1) /2 = 2$ is "same" padding → size preserved. Output $256 \times 256 \times 16$ .
Pool 1. $⌊(256 - 2 + 0) /2 ⌋ + 1 = 127 + 1 = 128$ . Halves each side → $128 \times 128 \times 16$ .
Conv 2. $⌊(128 - 3 + 2 \cdot 1) /1 ⌋ + 1 = 127 + 1 = 128$ . Again "same" ( $p = (3 - 1) /2 = 1$ ). Output $128 \times 128 \times 32$ .
Pool 2. $⌊(128 - 2) /2 ⌋ + 1 = 63 + 1 = 64$ . → $64 \times 64 \times 32$ .
Parameters. Conv 1: $F (k^{2} C + 1) = 16 (5^{2} \cdot 1 + 1) = 16 \cdot 26 = 416$ . Conv 2: $32 (3^{2} \cdot 16 + 1) = 32 (144 + 1) = 32 \cdot 145 = 4640$ . Pools: $0$ each (pooling has zero learnable parameters — see the recall box). Why this step? This is the practical payoff — a full crack-detector front-end needs only $416 + 4640 = 5056$ weights, independent of the $256 \times 256$ image size (conv parameters don't scale with image size). A fully-connected first layer would need $\sim 25 6^{2} \times 25 6^{2} = 4.3 \times 1 0^{9}$ .
Verify: sizes $256 \to 128 \to 128 \to 64$ ✓; params $416$ and $4640$ ✓.

Example 9 — Cell I: exam twist — solve for the unknown

Worked example Find the padding for a target output

You must map $W_{in} = 28$ to $W_{o u t} = 14$ using $k = 3, s = 2$ . What integer $p$ works?

Forecast: with $s = 2$ we roughly halve $28$ to $14$ — but does the arithmetic need padding, or does the floor already do it?

Invert the formula. Start from $W_{o u t} = ⌊(W_{in} - k + 2 p) / s ⌋ + 1$ . Drop the floor first (pretend the division is exact): $14 - 1 = (28 - 3 + 2 p) /2 \Rightarrow 13 \cdot 2 = 25 + 2 p \Rightarrow 26 = 25 + 2 p \Rightarrow p = 0.5$ . Why this step? Solving for the unknown is just algebra — but $p$ must be an integer (you cannot pad half a pixel), so $0.5$ is impossible exactly. The fraction is a warning that we must now bring the floor back and test the neighbouring integers $p = 0$ and $p = 1$ .
Test $p = 0$ . $⌊(28 - 3 + 0) /2 ⌋ + 1 = ⌊ 12.5 ⌋ + 1 = 12 + 1 = 13$ . Too small by one. Why this step? With the floor restored, $p = 0$ undershoots the target, so it is rejected.
Test $p = 1$ . $⌊(28 - 3 + 2) /2 ⌋ + 1 = ⌊ 13.5 ⌋ + 1 = 13 + 1 = 14$ . ✓ $p = 1$ is the answer. Why this step? The floor absorbs the leftover half ( $13.5 \to 13$ ), so the integer $p = 1$ lands exactly on the target even though the "exact" solve gave a fraction. Conclusion: when inverting the size formula, never trust the fractional solve — always re-check integer candidates against the floored formula.
Verify: $⌊(28 - 3 + 2 \cdot 1) /2 ⌋ + 1 = ⌊ 13.5 ⌋ + 1 = 14.$ ✓ Target hit with $p = 1$ .

Example 10 — Cell J: the empty / invalid case

Worked example When is the output non-existent?

Input $W_{in} = 3$ , kernel $k = 5$ , $p = 0$ , $s = 1$ . Is a valid convolution possible? If not, find the smallest padding that rescues it.

Forecast: what does the formula give, and can an output size be zero or negative?

Plug in. $W_{o u t} = ⌊(3 - 5 + 0) /1 ⌋ + 1 = ⌊ - 2 ⌋ + 1 = - 2 + 1 = - 1$ . Why this step? A $5 \times 5$ kernel cannot fit inside a $3 \times 3$ image — the numerator $W_{in} - k = - 2$ goes negative, and the formula returns a non-positive number.
Interpret the non-positive result. $W_{o u t} \leq 0$ means no valid kernel position exists; the layer is undefined, and real libraries raise a shape error here. This is the degenerate boundary of the whole topic. Why this step? It tells you the precondition every earlier example silently satisfied: convolution needs at least one place for the kernel to sit.
Find the rescue padding. We need the numerator non-negative: $W_{in} - k + 2 p \geq 0 \Rightarrow 3 - 5 + 2 p \geq 0 \Rightarrow 2 p \geq 2 \Rightarrow p \geq 1$ . Take the smallest, $p = 1$ : $W_{o u t} = ⌊(3 - 5 + 2) /1 ⌋ + 1 = 0 + 1 = 1$ — one valid output. Why this step? Padding grows the effective width $W_{in} + 2 p$ until the kernel fits. The general precondition is $W_{in} + 2 p \geq k$ .
Verify: unpadded gives $- 1$ (invalid) ✓; with $p = 1$ gives $1$ (valid) ✓.

Recall

Recall The scenario checklist

Before trusting any conv/pool answer, which four things do you sanity-check? ::: Sign of the output (can be negative pre-activation), the floor when numerator isn't divisible by stride, that $W_{in} + 2 p \geq k$ (else invalid), and that pooling has zero parameters. "Same" padding rule for stride 1 ::: $p = (k - 1) /2$ , which makes $W_{o u t} = W_{in}$ . When does stride force $W_{o u t} = 1$ ? ::: When $s > W_{in} - k$ (with $p = 0$ ): the kernel lands only at position 0. What does $F$ stand for? ::: The number of filters in a conv layer, i.e. the number of output channels/feature maps it produces.
