Exercises — C compilation — preprocessor, compiler, assembler, linker

(a) Preprocessor (cpp) — text substitution of #include. (b) Assembler (as) — mnemonics → machine code. (c) Linker (ld) — matches undefined symbols to definitions. (d) Compiler (cc1) — parses, type-checks, emits assembly. What it looks like: point at each numbered arrow in the s01 figure. #include sits on arrow ① (cpp), mnemonics→bytes on arrow ③ (as), symbol resolution on arrow ④ (ld), type-checking on arrow ② (cc1).

$\text{.c}\to \text{.i}\to \text{.s}\to \text{.o}\to \text{executable}$ Why this order: each stage lowers the level by exactly one step. You cannot skip: the assembler needs .s, and .s only exists after the compiler ran. Mnemonic: "I Saw Our executable" — i, s, o, exe.

gcc -E ::: stop after preprocessing → .i gcc -S ::: stop after compiling → .s gcc -c ::: stop after assembling → .o (not runnable) gcc (no flag) ::: run the whole pipeline → executable Picture: each flag is a "STOP HERE" gate drawn under its file box in the s01 figure.

The comment is stripped, and PI and AREA(r) are substituted as text only:

double a = (3.14*(2)*(2));

That is the entire output of gcc -E: a string of characters. The preprocessor does not multiply anything — the file still literally contains (3.14*(2)*(2)), not 12.56. (Only much later, at compile or run time, will something evaluate that expression to $12.56$.) Why parentheses matter here: even with argument 2 there is no ambiguity, but the macro author wrapped PI*(r)*(r) defensively so that AREA(1+1) would also work. Text substitution has no idea what a "number" is.

gcc -E math.c -o math.i    # (a) preprocessed source
gcc -S math.c              # (b) produces math.s automatically
gcc -c math.c              # (c) produces math.o automatically

Note: -S and -c name the output file for you (.s, .o); -E prints to stdout unless you redirect with -o.

Three: preprocessor → compiler → assembler. It skips the linker, which is exactly why the result (.o) is not runnable. Picture: on the s01 figure, -c walks arrows ①②③ and stops before arrow ④.

(a) Compiler (cc1) — a syntax error; the parser choked. (b) Linker (ld) — a definition was never found among your .o files and libraries. (c) Compiler (cc1) — a declaration is missing (you forgot #include <stdio.h>), caught during type-checking, not linking. (d) Linker (ld) — two object files each defined the same symbol; the linker cannot choose. Key distinction: undeclared (compiler: "I don't know this name's signature") vs undefined reference (linker: "I know the signature, but no code exists"). See Object Files and Symbol Tables.

math.h supplies only the declaration (the promise "double sqrt(double) exists"). That satisfies the compiler. But the compiled code for sqrt lives in the math library libm, which is not linked by default. You must tell the linker to include it:

gcc prog.c -lm

Header = promise; library = delivery. This is the parent note's rule made concrete. Contrast with printf: its code is in libc, which is linked automatically.

Substitution gives int y = ((i++)*(i++));. The macro duplicated i++, so i would be incremented twice in one expression with no sequence point between them. That makes this undefined behaviour: the C standard guarantees nothing about the result — the value of y, the final value of i, and even whether the program crashes are all unspecified. Any number you happen to observe (some compilers print 30, others 36, others something else) is incidental, never something you may rely on. The only correct answer is: the behaviour is undefined; do not write this. The lesson: a macro is text, not a function. A function would evaluate i++ once into a temporary; the macro pastes it verbatim. This is why side-effecting arguments break macros — see C Preprocessor Directives.

gcc -c main.c        # -> main.o  (greet is UNDEFINED here)
gcc -c greet.c       # -> greet.o (greet is DEFINED here)
gcc main.o greet.o -o app   # linker resolves greet, makes ./app

What happens at link: main.o's symbol table lists greet as undefined; greet.o lists it as defined. The linker matches them, performs relocation (assigns final addresses), and staples on the _start entry code that calls main.

Only greet.c changed, so:

• Re-run preprocessor + compiler + assembler on greet.c → new greet.o.
• main.o is untouched and reused.
• Re-run the linker on main.o + new greet.o → new app.

gcc -c greet.c        # rebuild only this object
gcc main.o greet.o -o app   # relink

Why this is fast: we skipped recompiling main.c entirely. This is the whole reason object files exist and the engine behind Makefiles and Incremental Builds.

-O2 affects the compiler stage (cc1) — it rearranges/eliminates instructions to produce faster assembly. See Compiler Optimization Levels (-O0..-O3). It does not change which symbols are defined/undefined (the interface), so the symbol table's names are the same — the machine code behind them is just faster/smaller. That is why you can optimize one .o without re-linking logic changing.

static at file scope gives the symbol internal linkage — helper is not exported in util.o's symbol table. So main.o has helper as undefined, and no .o provides it publicly. Result: linker error, undefined reference to 'helper'. The compiler is fine (it trusts the declaration in main.c). The subtlety: the code exists in util.o, but is deliberately hidden. This is the "definition present but invisible" degenerate case — different from "definition absent." See Object Files and Symbol Tables.

• app_stat: the linker copies printf's code from libc.a into the executable → it is self-contained, larger, no run-time library needed.
• app_dyn: the executable stores only a reference ("find printf in libc.so at run time"); the loader resolves it when you launch → smaller file, but libc.so must exist on the machine. This is exactly the Static vs Dynamic Linking trade-off: size + self-containment vs sharing + smaller binaries.

Linker fails: multiple definition of 'main'. Mirror image: an undefined reference = zero definitions found; a multiple definition = more than one found. The linker's job is to match each undefined symbol to exactly one definition. Both zero and two violate "exactly one." These are the two failure poles around the healthy case of one definition.

(i) After cpp: return ((3+1)*(3+1)); — this is still just text; no arithmetic has happened yet. (ii) Compiles cleanly — valid C. During compilation the constant expression is folded. (iii) Links cleanly — main defined, no external symbols. (iv) The folded value is $((3+1)\times (3+1))=4\times 4=16$, so the program returns 16; the shell exit code is 16 (fits in the 0–255 range). Contrast the trap: had the macro been #define SQ(x) x*x, the pasted text would be 3+1*3+1, which C evaluates with * before + as 3 + (1*3) + 1 = 7. The parentheses in the good macro are what force the answer 16, not 7 — precedence is decided by the pasted text, not by the macro's "intent." This is why macro parameters are always wrapped in parentheses.

Which tool spoke ::: syntax/undeclared/type → compiler (cc1); undefined or multiple definition → linker (ld) Header changed, how many objects rebuild ::: every object whose .c includes that header static function called cross-file ::: linker undefined reference (code exists but not exported) -lm needed because ::: math.h is only the declaration; sqrt code lives in libm, not linked by default
