Jahn-Teller distortion

WHAT is it?

The key trigger word is degeneracy that is unevenly occupied.

In an octahedral field the five d-orbitals split into:

== $t_{2g}$ == ( $d_{xy}, d_{yz}, d_{xz}$ ) — lower, point between ligands.
== $e_g$ == ( $d_{z^2}, d_{x^2-y^2}$ ) — higher, point at ligands.

A JT distortion occurs when either set is degenerate but unequally filled.

WHY does it happen?

The strong vs weak rule:

$e_g$ orbitals point directly at the ligands → uneven filling here causes a strong, observable distortion.
$t_{2g}$ orbitals point between ligands → uneven filling causes only a weak, often unobservable distortion.

HOW does the energy actually split? (Derivation from scratch)

Consider an elongation along the $z$ -axis: the two axial ligands move away from the metal.

Step 1 — split the $e_g$ set.

$d_{z^2}$ has its lobes along $z$ → repulsion drops → energy lowers by $\delta_1/2$ .
$d_{x^2-y^2}$ lies in the $xy$ plane → repulsion increases → energy raises by $\delta_1/2$ .

Why this step? Because the perturbation must conserve the centre of energy ("barycentre"): one goes down as much as the other goes up.

Step 2 — split the $t_{2g}$ set.

$d_{xz}, d_{yz}$ (have $z$ component) → lower by $\delta_2/3$ .
$d_{xy}$ (purely in-plane) → raise by $2\delta_2/3$ (keeping barycentre).

Why barycentre weighting? Two orbitals go down, one goes up; the signed total must be zero: $-2(\delta_2/3) + (2\delta_2/3)=0$ . ✓

Step 3 — net stabilization. For a configuration, the JT stabilization energy is the sum of (electrons in lowered orbitals)×(drop) minus (electrons in raised orbitals)×(rise):

WHICH configurations distort?

The distortion is strong when the $e_g$ set is unevenly occupied:

Configuration	$e_g$ occupation	JT?
$d^9$ (Cu²⁺)	$e_g^3$ ( $t_{2g}^6 e_g^3$ )	Strong
high-spin $d^4$ (Cr²⁺, Mn³⁺)	$e_g^1$	Strong
low-spin $d^7$ (Co²⁺ ls, Ni³⁺)	$e_g^1$	Strong
$d^3$ , $d^6$ ls, $d^8$ , $d^{10}$	$e_g$ evenly filled (0,0,2)	None

Weak (usually ignored) when only $t_{2g}$ is uneven: e.g. $d^1, d^2, t_{2g}$ low-spin cases.

Flashcards

Jahn–Teller theorem statement

A non-linear molecule in a degenerate electronic ground state distorts geometrically to remove the degeneracy and lower its energy.

Trigger condition for JT distortion

Uneven (asymmetric) occupation of a degenerate set of orbitals.

Which orbital set gives STRONG distortion and why

e_g

— its lobes point directly at the ligands, coupling strongly to bond lengths.

Which gives only WEAK distortion

t_{2g}

— lobes point between ligands, weak coupling.

Classic strong-JT ion

Cu²⁺ (

d^9

t_{2g}^6 e_g^3

d

counts with strong JT (high spin)

d^9

, high-spin

d^4

, low-spin

d^7

(uneven

e_g

d

counts with NO JT

d^3

d^8

d^{10}

, low-spin

d^6

(evenly filled sets).

Effect on Cu²⁺ octahedron geometry

Elongation along z → 4 short + 2 long M–L bonds.

Why elongation lowers

d_{z^2}

Axial ligands move away → less repulsion on the z-pointing orbital.

Does barycentre stay fixed during splitting

Yes — total energy of a split set is conserved; rises balance drops.

Recall Feynman: explain to a 12-year-old

Picture a metal ball wearing a cage of 6 marbles, perfectly even. The ball has little electron "pockets." If the electrons sit lopsidedly — more on one side than the other — the cage is uncomfortable. So it stretches: two marbles slide a bit farther away. This makes the crowded electrons more relaxed and the whole thing happier (lower energy). That stretching is the Jahn–Teller effect. It happens a lot for copper, which is why copper compounds look "squashed."

Connections

Crystal Field Theory — provides the $t_{2g}/e_g$ splitting JT acts on.
Octahedral Splitting and $\Delta_o$ — the parent energy diagram.
High-spin vs Low-spin Complexes — decides $e_g$ occupation, hence JT.
Colour of Transition Metal Complexes — JT splitting adds extra absorption bands (e.g. broad Cu²⁺ band).
Stability and Distortion in $d^9$ Cu(II) — direct application.
Tetrahedral vs Octahedral Geometry — where distortions are strong vs weak.

Concept Map

Hinglish (regional understanding)

Intuition Hinglish mein samjho

Dekho, Jahn-Teller distortion ka basic idea simple hai. Octahedral complex mein metal ke d-orbitals do groups mein split hote hain: niche wale $t_{2g}$ (teen orbital) aur upar wale $e_g$ (do orbital). Ab agar koi degenerate set (jaha orbitals same energy ke hain) mein electrons uneven baithe hain — matlab ek orbital mein zyada, doosre mein kam — to molecule "uncomfortable" feel karta hai. Energy bachane ke liye wo apni shape thodi distort kar leta hai (usually z-axis pe stretch ho jaata hai), jisse degeneracy toot jaati hai aur total energy kam ho jaati hai.

Sabse important rule: strong distortion sirf tab hoti hai jab $e_g$ set uneven ho. Kyun? Kyunki $e_g$ orbitals ( $d_{z^2}$ , $d_{x^2-y^2}$ ) seedha ligands ki taraf point karte hain, to bond length pe inka effect bada hota hai. $t_{2g}$ orbitals ligands ke beech mein point karte hain, isliye unki unevenness se sirf "teeny" weak distortion aati hai jo aksar ignore kar dete hain.

Classic example hai Cu²⁺ ( $d^9$ ): configuration $t_{2g}^6 e_g^3$ hai, to $e_g$ mein 3 electrons hai — ye toh uneven hona hi pad gaya (ek orbital full, ek half). Result: octahedron z-axis pe stretch ho jaata hai, 4 short + 2 long bonds banti hain. Isi tarah high-spin $d^4$ (Mn³⁺, Cr²⁺) aur low-spin $d^7$ bhi strong distortion dikhate hain. Lekin $d^3$ , $d^8$ , $d^{10}$ mein sets evenly filled hote hain, to koi distortion nahi.

Exam tip: pehle d-count likho, fir $t_{2g}/e_g$ filling likho, fir dekho $e_g$ uneven hai ya nahi. Agar haan → strong JT. Yahi 20% concept poore questions ka 80% cover kar deta hai.
