3.7.16Algorithm Paradigms

Backtracking — state-space tree, pruning

1,928 words9 min readdifficulty · medium2 backlinks

What is the state-space tree?

WHAT pruning needs: a fast bounding / feasibility test isValid(state) that returns false whenever the partial solution already violates a constraint.


The universal template (derive it, don't memorize)

We want all solutions. Start from "what is a solution?" — a sequence of choices c1,c2,,cnc_1, c_2, \dots, c_n. To enumerate all sequences we naturally recurse:

def backtrack(state):
    if is_complete(state):
        record(state)
        return
    for choice in candidates(state):
        if is_valid(state, choice):     # <-- PRUNE here, before going deeper
            state.add(choice)           # make the move
            backtrack(state)            # explore
            state.remove(choice)        # UNDO = backtrack
Figure — Backtracking — state-space tree, pruning

Worked Example 1 — N-Queens (n = 4)

Place 4 queens on a 4×44\times4 board, no two attacking. We decide one queen per row, choosing its column.

State = list col[] where col[r] = column of the queen in row r.

Validity test — when placing in row r, column c, check all earlier rows i<r:

  • same column? c=col[i]c = \text{col}[i]
  • same diagonal? ri=ccol[i]|r-i| = |c - \text{col}[i]|

Brute force = 44=2564^4=256 leaves. Backtracking visits far fewer because dead branches die early.


Worked Example 2 — Subsets that sum to a target

Choose a subset of [2, 4, 6, 8] summing to 6. Decision per element: include or exclude.


Why pruning is the whole game (the 80/20)

Complexity (forecast-then-verify): without pruning, the tree has up to bdb^d nodes (branching bb, depth dd). Pruning cannot improve the worst case (an adversarial input may prune nothing) but slashes the average case dramatically. So Big-O stays O(bd)O(b^d); real runtime plummets.


Common mistakes (steel-manned)


Recall Feynman: explain to a 12-year-old

Imagine a maze of doors. You walk forward opening one door at a time. The moment a hallway hits a wall, you don't keep wandering — you walk back to the last door and try a different one. Smart bit: if you see a sign saying "no exit this whole wing", you skip the entire wing instead of checking every room. That sign-reading is pruning; the walking back is backtracking.


Flashcards

What is a state-space tree?
A tree whose root is the empty partial solution, edges are individual decisions, nodes are partial solutions, and leaves are complete solutions or dead-ends; explored via DFS.
In backtracking, what does "pruning" mean?
Refusing to expand a non-promising node — cutting its entire subtree — because the partial solution already violates a constraint.
Why must is_valid be checked BEFORE recursing, not at the leaf?
So invalid partial choices' whole subtrees are never generated, turning brute force into early-abandon search.
What three operations form the backtracking loop body?
Make the move (add), recurse (explore), undo the move (remove/backtrack).
Why is the "undo" step essential?
A single mutable state is shared across all branches; without undo, sibling/parent states get corrupted.
Does pruning improve worst-case Big-O?
No — an adversarial input may prune nothing, leaving O(b^d). It improves average/typical runtime only.
N-Queens: validity test for placing queen at row r, col c?
For every earlier row i<r: c != col[i] (column) AND |r-i| != |c-col[i]| (diagonal).
Difference between plain DFS and backtracking?
Backtracking is DFS over an implicit solution tree plus an early feasibility prune and explicit state undo to reuse one state.
What is a "promising/feasible" node?
A partial solution that could still be extended into a valid complete solution.
In subset-sum, what is a good pruning rule?
If running_sum > target, stop expanding — adding more elements can only increase the sum.

Connections

  • Recursion — backtracking is recursion with state mutation + undo.
  • Depth-First-Search — the traversal order of the state-space tree.
  • Branch-and-Bound — backtracking + a numeric bound to prune for optimization.
  • Dynamic-Programming — when subtrees overlap, memoize instead of re-exploring.
  • N-Queens · Sudoku-Solver · Permutations-and-Combinations — canonical applications.
  • Time-Complexity — why pruning helps average not worst case.

Concept Map

models search as

root is

edge is

leaf is

explored in

uses test

fails then

kills exponential

realized by

rhythm

missing undo

filters choices in

applied to

Backtracking

State-Space Tree

Empty partial solution

One decision

Complete solution or dead-end

Depth-First order

isValid feasibility test

Prune subtree

Dead-ends in one cut

Recursive template

make explore undo

Corrupts siblings

N-Queens example

Hinglish (regional understanding)

Intuition Hinglish mein samjho

Backtracking ka basic idea simple hai: solution ko ek-ek decision karke banao, aur jaise hi koi partial choice galat lage, turant us poore branch ko chhod do (prune karo) aur peeche ja kar dusra option try karo (backtrack). Saari possible decision-sequences milke ek tree banati hain jise state-space tree kehte hain — root pe khaali solution, har edge ek decision, aur leaves pe complete solutions. Hum is tree ko DFS se ghoomte hain.

Asli magic pruning mein hai. Maan lo tum N-Queens solve kar rahe ho aur row 0 mein queen rakhi. Ab row 1 mein agar koi column same column ya same diagonal pe aata hai, to wahin reject karo — us choice ke neeche ka poora subtree explore karne ki zaroorat hi nahi. Isse exponentially saare dead-ends ek hi jhatke mein cut ho jaate hain. Yaad rakho: validity check recurse karne se pehle karna hai, leaf pe nahi — warna pura brute-force tree ban jayega aur fayda zero.

Ek important baat: har "move add karo" ke baad recursion khatam hone par "move undo karo" zaroori hai, kyunki ek hi state object saare branches share karte hain. Add aur remove ka symmetry tootta hai to siblings ka data corrupt ho jata hai — ye sabse common bug hai. Aur yaad rakho, pruning worst-case Big-O ko improve nahi karta (adversarial input pe kuch prune hi nahi hoga, O(bd)O(b^d) hi rahega), par real-life average case mein speed bahut zyada badha deta hai. Mantra: Choose → Explore → Un-choose, aur jo promising nahi uska branch kaat do.
