Logistic regression and the sigmoid function

WHAT is logistic regression?

WHY the sigmoid, specifically? (Derivation from odds)

We want a function that turns a linear score into a probability. Start from odds, not probability.

Formula Derivation: log-odds → sigmoid

Step 1. Let $p = P(y=1\mid x)$ . The odds are $\dfrac{p}{1-p}\in(0,\infty)$ . Why this step? Probability lives in $[0,1]$ (bounded), but a linear model outputs anything. Odds live in $(0,\infty)$ — closer, but still one-sided.

Step 2. Take the log-odds (called the logit): $\ln\dfrac{p}{1-p}\in(-\infty,\infty)$ . Why this step? Now the range matches a linear function's range exactly. So we can boldly set $\ln\frac{p}{1-p} = w^\top x + b = z.$

Step 3. Solve for $p$ . Exponentiate: $\dfrac{p}{1-p} = e^{z}$ . Why? Undo the log to isolate $p$ .

Step 4. $p = e^{z}(1-p) \Rightarrow p + p e^{z} = e^{z} \Rightarrow p(1+e^z)=e^z$ $p = \frac{e^z}{1+e^z} = \frac{1}{1+e^{-z}} = \sigma(z).$ Why? Divide top and bottom by $e^z$ to get the clean canonical form.

So the sigmoid is not arbitrary — it is the inverse of the log-odds. Assuming log-odds are linear in $x$ forces the sigmoid.

HOW do we train it? (The loss and its gradient)

We can't use squared error nicely (it's non-convex for sigmoid). Instead use maximum likelihood.

Formula Derivation of the loss (cross-entropy)

Step 1. For one example, the label is Bernoulli: $P(y\mid x) = p^{y}(1-p)^{1-y}, \quad p=\sigma(z).$ Why? If $y=1$ it gives $p$ ; if $y=0$ it gives $1-p$ . One formula, both cases.

Step 2. Likelihood of all $m$ examples = product. Products are hard, so take the log: $\ell = \sum_i \big[y_i\ln p_i + (1-y_i)\ln(1-p_i)\big].$ Why log? Turns product into sum, and log is monotonic so the maximizer is unchanged.

Step 3. We minimize the negative (a cost to descend): $J = -\frac{1}{m}\sum_i \big[y_i\ln p_i + (1-y_i)\ln(1-p_i)\big].$ This is the binary cross-entropy (log loss). It is convex in $w$ , so gradient descent finds the global minimum.

The decision boundary

Worked examples

Worked example Example 2 — One gradient step

Two features, $w=(0,0)$ , $b=0$ , $\alpha=0.5$ . One data point $x=(1,2)$ , $y=1$ .

Step 1: $z=0 \Rightarrow p=\sigma(0)=0.5$ . Why? Starting weights give a neutral guess.
Step 2: error $= p-y = 0.5-1 = -0.5$ .
Step 3: $\partial J/\partial w_1 = (-0.5)(1)=-0.5$ ; $\partial J/\partial w_2=(-0.5)(2)=-1$ .
Step 4: $w_1 \leftarrow 0 - 0.5(-0.5)=0.25$ ; $w_2\leftarrow 0-0.5(-1)=0.5$ .
Why did weights go up? We under-predicted a positive example, so the model pushes $z$ higher next time.

Common mistakes

Flashcards

What does the sigmoid function map its input to?

The open interval

(0,1)

, interpreted as a probability.

Write the sigmoid formula.

\sigma(z)=\dfrac{1}{1+e^{-z}}

What is

\sigma(0)

0.5

What is the derivative

\sigma'(z)

\sigma(z)(1-\sigma(z))

What quantity does logistic regression assume is linear in

x

The log-odds (logit),

\ln\frac{p}{1-p}=w^\top x+b

Why not use squared error for logistic regression?

It becomes non-convex and its gradient saturates when very wrong; cross-entropy is convex.

State the binary cross-entropy loss for one example.

-[y\ln p + (1-y)\ln(1-p)]

with

p=\sigma(z)

What is the gradient

\partial J/\partial w_j

\frac{1}{m}\sum_i (p_i-y_i)x_{ij}

— (pred−target)×input.

Where is the decision boundary?

Where

w^\top x + b = 0

(equivalently

p=0.5

); it is linear.

If log-odds

=1.1

, what are the odds and

p

Odds

=e^{1.1}\approx3

, so

p=0.75

Is logistic regression classification or regression?

Classification (name is historical).

Recall Feynman: explain to a 12-year-old

Imagine a machine that gives a "yes-ness score" — big positive means "definitely yes", big negative means "definitely no", zero means "no idea". But a score like 7 or −3 is confusing. So we pass it through a special squishy slide (the sigmoid) that turns any score into a number between 0 and 1 — like a percentage of confidence. Score of 0 → 50%. Big score → near 100%. We then teach the machine by nudging its dials whenever it's too confident and wrong, using the simple rule "how wrong you were × the input".

Connections

Linear Regression — supplies the linear score $z=w^\top x+b$ that sigmoid squashes.
Cross-Entropy Loss — the training objective derived from maximum likelihood.
Gradient Descent — optimizer that uses the $(p-y)x$ gradient.
Maximum Likelihood Estimation — the principle that justifies the loss.
Softmax Regression — multi-class generalization of the sigmoid.
Decision Boundaries — why the boundary here is a hyperplane.
Neural Networks — sigmoid as an activation function / a single logistic neuron.

Concept Map

Hinglish (regional understanding)

Intuition Hinglish mein samjho

Dekho, linear regression toh ek number predict karta hai jo kuch bhi ho sakta hai — minus infinity se plus infinity tak. Par jab sawaal "haan ya na" ka ho (spam hai ya nahi, tumor malignant hai ya nahi), tab humein ek probability chahiye jo 0 aur 1 ke beech ho. Iske liye hum pehle ek linear score nikalte hain $z = w^\top x + b$ , aur phir usko sigmoid function se dabaa dete hain: $\sigma(z)=1/(1+e^{-z})$ . Ye har score ko 0 aur 1 ke beech le aata hai, jise hum $P(y=1)$ maante hain.

Sigmoid koi random function nahi hai. Agar tum log-odds ( $\ln\frac{p}{1-p}$ ) ko linear maan lo, toh algebra se solve karne par automatically sigmoid nikal aata hai. Isliye ye natural choice hai. Boundary wahan hoti hai jahan $z=0$ , matlab $p=0.5$ — aur ye boundary hamesha ek seedhi line/hyperplane hoti hai, isiliye ise "linear" model kehte hain.

Training ke liye squared error mat use karo — wo yahan non-convex ho jaata hai aur galat jagah gradient zero ho jaata hai. Iski jagah cross-entropy (log loss) use karte hain, jo maximum likelihood se aata hai aur convex hota hai. Sabse pyari baat: gradient ban jaata hai bilkul simple — $(p - y)\cdot x$ , yaani (prediction minus asli answer) guna input. Bilkul linear regression jaisa, bas prediction ki jagah sigmaid output.

Yaad rakhne ka trick: "Log-odds go linear, then squash." Aur sigmoid ka derivative? "s times one-minus-s" — $\sigma(1-\sigma)$ . Bas itna pakka kar lo toh logistic regression tumhaara dost ban jaayega.
